1.Multifunction
2.High-efficiency
3.Strong power
4.Low consumption
5.Easy operation
6.Simply maintenance
Spezifikationen
| ▶Technical Specification | ||||||
| Basic | parameter | |||||
| Weight | 26650 kg Cummins QSF3.8 124/2050 kW/rpm 600 mm | |||||
| Engine | ||||||
| Rated power | ||||||
| Max diameter | ||||||
| Performance parameter | ||||||
| Max slewing speed | 11~15 r/min | |||||
| Travel speet | 3.2/4.7 km/h | |||||
| Fuel tank | 350 L | |||||
| Hydraulic tank | 210 L | |||||
| Gradeability | 35° | |||||
| Operation | parameter | |||||
| Max.Operating Radius Man.Operating Depth Max.Operating Height Platform Tail Turning Radius | 8577 mm 5300 mm 8900 mm 2830 mm | |||||
| Transportation dimension | ||||||
| Length | 9465 mm | |||||
| Width | 3000 mm | |||||
| Height | 4080 mm | |||||
| Other Parameter | ||||||
| Lenght Of Track | 4406 mm | |||||
| Track Gauge | 3610 mm | |||||
| Width Of Track Height Between | 600 mm 782 mm | |||||
