F60 Harvester Head

Yuchai's range of harvesting heads integrate multiple functions, including felling, delimbing, length measuring, cutting to length, and stacking. They are characterized by intelligent operation, coordinated movements, and high precision, making them widely applicable for harvesting various fast-growing plantation timber such as eucalyptus, fir, and pine. Different rollers can be equipped depending on the tree species and specific felling requirements.

Specifications

F60 Parameter NameUnitImperial unit parametersUnitMetric units parameters
Chain Pitchinch0.404inch0.404
Rollers Quantitypcs3pcs3
Rollers Diameterft'in"1'3.7"mm400
Max. Opening of Rollersft'in"1'11.6"mm600
Max. Feed Forcelbf5620.2kN25
Max. Feed Speedft/s0-19.7m/s0-6
Max. Delimbing Diameterft'in"1'4.5"mm420
Optimal Tree Diameter Less Thanft'in"≤1'4.5"mm≤420
Knives Quantity-2+2+2+1-2+2+2+1
Diameter Tip to Tipft'in"1'3.7"mm400
Front Knives Max. Openingft'in"2'1.2"mm640
Rear Knives Max. Openingft'in"2'1.6"mm650
Operating Hydraulic Pressurepsi4061.1MPa28
Required Hydraulic Flowgpm63.4-66.0L/min240-250
Required Powerhp114.0~134.1KW85~100
Operating VoltageV24V24
Suitable Excavator Tonnageshort ton13.2-27.6Ton12-15
Width (Head Closed / Head Open)ft'in"4'11.1"mm1500
Overall Lengthft'in"4'8.9"mm1445
Overall Heightft'in"5'0.2"mm1530
Equipment Weightlb2314.9kg1050
