Hydraulic Steel/Rock Grab

Applicable objects: simple soil loosening, cleaning debris, loading and unloading.

Main features: NM400 steel, light weight and wear-resistant:The pin is made of 42CrMo alloy steel, with built-in oil passage, high strength and good toughness,Rotary motor imported from Switzerland;Use vertical car motor rotation system, 3600 rotation, with car brake function;The oil cylinder adopts honing tube, imported HALLITE oil seal, short working cycle and long life;The teeth are made of manganese molybdenum alloy material, which is durable.

Inquire Now Next Product

Specifications

Parameter	Unit	Model
Parameter	Unit	YCSR02CA	YCSR04CA	YCER06CA	YCSR08CA	YCSR10CA	YCSR08CB
Suitable Excavator	ton	1.5-3.5	7-11	12-16	17-23	24-30	24-30
Weight	kg / lb	185 / 407.9	240 / 529.1	530 / 1168.4	960 / 2116.4	1220 / 2689.6	815 / 1796.8
Max Jaw Opening	mm / ft'in"	1200 / 3'11.2"	1300 / 4'3.2"	1850 / 6'0.8"	2170 / 7'1.4"	2540 / 8'4.0"	2000 / 6'6.7"
Height	mm / ft'in"	1095 / 3'7.1"	850 / 2'9.5"	1765 / 5'9.5"	2160 / 7'1.0"	2440 / 8'0.1"	1635 / 5'4.4"
Two Tine Width	mm / ft'in"	286 / 0'11.3"	210 / 0'8.3"	354 / 1'1.9"	460 / 1'6.1"	550 / 1'9.7"	430 / 1'4.9"
Three Tine Width	mm / ft'in"	476 / 1'6.7"	350 / 1'1.8"	618 / 2'0.3"	760 / 2'5.9"	930 / 3'0.6"	750 / 2'5.5"
