1.Structural Reliability
2.Excellent Performance
3.Fuel saving and high efficiency
4.Brand new large cabin
5.Comfortable driving experience
6.Convenient maintenance
Download Brochure
International brand engine
It is equipped with Yanmar 4TNV98C naturally aspirated engine, with an approved power of 44.4kW/2100rpm. Fuel-saving, low noise, sufficient power, low emission, and compliance with emission regulations.
Maximum excavation force at the same level
The maximum traction force of YC80 is 68kN, the digging force of bucket is 56KN, and the digging force of stick is 38KN, which ensures the effective exertion of strong digging force and makes the digging and hoisting more stable.
Higher energy efficiency ratio
Better fuel efficiency: In the common speed range, the average efficiency of YC80 is about 19% higher than that of the industry benchmark model
YUCHAI Little Dig
YUCHAI Heavy Industry co., Ltd. was founded in 1989. It is the first excavator enterprise in China to produce micro-excavators and sell them to the world. It is the largest small excavator production and export base in China and a state-level high-tech enterprise.
More than 30 years of innovation and development, to ensure high quality customers!
Rich apparel
More than 30 types of attachments, including a hydraulic hammer, bucket, quick-change device, wooden grab, simple grab pliers, ditch bucket, shell bucket, drilling tool, lawn mower, etc., are applied across more than 40 key working conditions, providing versatility in a wide range of working scenarios.
Easy maintenance
While the whole hood is kept, two openable side doors are added, and the three filters are centralized, so that all maintenance and inspection points are within reach.
All the main hydraulic hoses are arranged in the direction of the working device, which improves the convenience of detection and maintenance.
Lower fuel consumption
Optimize the blade shape to enhance the efficiency of bulldozing work. The unique design prevents soil from leaking from the upper part of the blade to the rear, significantly improving the efficiency of filling and leveling.
Two-way sliding seat
The interior is designed by professional ergonomics, the handles and switches are arranged reasonably, and the operation is natural and comfortable, which can effectively reduce fatigue.
Famous seats in the industry, with suspension damping, can adjust damping according to body weight, and can be laid down over 135.
The position of the seat and the control box can be adjusted independently, which can adapt to different figures or sitting positions.
Specifications
| Excavator Model | YC80 | |
| Basic parameter | ||
| Machine weight | kg | 7800 |
| Bucket capacity | m³ | 0.26 |
| Width of bucket | mm | 845 |
| Performance parameter | ||
| Engine model | Yanmar 4TNV99 / 4TNV98C (EuroV) | |
| Engine power | kW/rpm | 44.4/2100 / 42.4/2000 |
| Max. Gradeability | 35° | |
| Max. digging force of arm | kN | 38 |
| Max. digging force of bucket | kN | 56 |
| Traveling speed | km/h | 3.9/2.6 |
| Max. hauling force | kN | 68 |
| Slewing speed of platform | rpm | 9~13 |
| Operating parameter | ||
| Max. digging height | mm | 7112 |
| Max. digging depth | mm | 4022 |
| Max. digging radius | mm | 6390 |
| Max. digging radius on ground level | mm | 6248 |
| Max. dumping height | mm | 5055 |
| Min. slewing radius | mm | 1881 |
| Max. vertical digging depth | mm | 3515 |
| Max. dozer balde heigh | mm | |
| Mzx. dozer blade depth | mm | |
| Transportation dimension | ||
| Overall length | mm | 6215 |
| Overall width | mm | 2260 |
| Overall height | mm | 2705 |
| Other Parameter | ||
| Width of undercarriage | mm | 2150 |
| Length of track | mm | 2783 |
| Width of track | mm | 450 |
| Height between undercarriage and ground | mm | 380 |
| Height between platform and ground | mm | 790 |
| Platform tail turning radius | mm | 1881 |
| Length to center of rollers | mm | 2200 |
| Fuel tank capacity | L | 151 |
| Hydraulic oil tank capacity | L | 125 |
| Track gauge | 2200 | |
| Working Pressure | Mpa | 27.5 |
| Ground Contact Pressure | kPa | |
| Arm length | mm | 1650 |
| Boom length | mm | 3710 |
| Steering head angle | ||
| Flow rate | L/Min | 168+17.6 |
