Comparison of Advantages and Disadvantages of Excavator Systems

Mar. 28, 2026

Three-pump System vs Load Sensing System (LS System) for Excavators: Comparative Table of Advantages and Disadvantages :

Comparison Dimension	Three-pump System	Load Sensing System (LS System)	Core Difference Explanation
Basic Definition	Three independent pumps (normally two main pumps + one swing/auxiliary pump) with three-loop oil supply, enabling independent control of three simultaneous operations	Single/dual variable displacement pump + pressure compensator valve + LS signal oil circuit; oil supply on demand, with pressure and flow dynamically adjusted according to load	The three-pump system features "parallel branch operation", while the LS system adopts "intelligent overall scheduling"
Core Working Principle	1. Each of the three pumps is responsible for different operations (e.g., P1 for boom/bucket, P2 for arm/travel, P3 for swing/hammer) 2. Supports confluence function (oil supply by multiple pumps in combination) 3. Constant power control to fully utilize engine power	1. Load sensing: Shuttle valve collects the maximum load pressure 2. Pressure regulation on demand: Pump output = load pressure + pressure difference of 1.5-2.5MPa 3. Independent flow: Pressure compensator valve ensures that flow is only related to joystick opening, independent of load	The three-pump system allocates fixed oil flow (like "dividing a cake"), while the LS system generates oil flow based on actual demand (like "baking a cake on demand")
Energy-saving Effect	Moderate (10%-15% more fuel-efficient than traditional fixed displacement pumps); Hitachi TRIAS three-pump system has a measured fuel saving rate of 9%	Excellent (25%-40% more fuel-efficient than traditional systems); no overflow loss, and flow and pressure are automatically reduced under light load	The LS system has obvious advantages under light load conditions, while the three-pump system achieves high efficiency during confluence under heavy load
Compound Operation Performance	Good (enabling complete independence of three simultaneous operations), but oil competition still occurs during multiple simultaneous operations	Excellent (no mutual interference between operations); pressure compensator valve ensures consistent pressure difference of each oil circuit with stable speed, represented by Caterpillar's PPPC technology	The LS system features smoother operation, easy to master for novice operators, and is suitable for precision operations
Response Speed	Fast (each pump works independently without LS signal delay)	Ultra-fast (millisecond-level signal transmission), with instant adjustment of pressure and flow when load changes abruptly	The LS system delivers more accurate dynamic response, while the three-pump system has a more direct response
Structural Complexity	Moderate (three pumps + confluence valve group)	High (precision LS pump + pressure compensator valve + shuttle valve + LS oil circuit), with high requirements for manufacturing precision	The LS system has a higher technical threshold, while the three-pump system features a more intuitive structure
Procurement and Maintenance Cost	Moderate (three pumps with mature technology)	High (precision core components, professional equipment required for maintenance, and expensive spare parts)	The LS system requires a large initial investment and has high long-term maintenance costs
Reliability	High (mature technology, scattered fault points, and single pump failure does not affect other circuits)	Moderate (LS signal oil circuit is prone to blockage, pressure compensator valve is susceptible to wear, and extremely high requirements for hydraulic oil cleanliness)	The three-pump system has better "fault tolerance", while the LS system is more delicate in maintenance
Applicable Scenarios	1. Large excavators (above 30 tons) 2. Mining/heavy-duty operations (requiring high confluence power) 3. Users sensitive to cost but with demands for independent multiple operations	1. Medium and large excavators (mainstream 15-45 tons) 2. Municipal/construction/precision operations (requiring accurate operation) 3. Long-term light to medium load conditions (obvious fuel-saving advantages)	The three-pump system is suitable for "relying on high power for heavy tasks", while the LS system is for "precision and high efficiency"
Typical Manufacturer Applications	Hitachi TRIAS system, some Komatsu models, domestic Kaiyuan Zhifu, etc.	Caterpillar (PPPC), Komatsu (negative flow + LS), Sany, Yuchai, XCMG high-end models, etc.	LS system is the mainstream choice for international first-tier brands; both three-pump and LS systems are adopted by domestic manufacturers
Main Disadvantages	1. Flow waste of some pumps under light load2. Still speed fluctuation during multiple simultaneous operations3. Complex confluence control with high fault probability	1. Complex structure and high maintenance cost2. High requirements for hydraulic oil cleanliness (above NAS Class 7)3. Lower confluence power than the three-pump system under extreme heavy load	The three-pump system's drawbacks lie in "energy waste", while the LS system's in "delicate maintenance"

Popular Summary

· Three-pump system: Like three independent chefs cooking their own dishes separately; they can cooperate when there are many orders (multiple operations) but may compete for ingredients (oil flow). It is suitable for cooking heavy dishes (heavy-duty operations).

· Load sensing system: Like an intelligent head chef who first clarifies the customers' needs (load) and then prepares ingredients accurately (pressure and flow) without waste, ensuring consistent taste (stable operation) of dishes. It is suitable for making delicate dishes (precision operations).
